Карбюратор в сборе.. Not Shown 10 Models Only (CARBURETOR ASSY.. Not Shown 10 Models Only)

Карбюратор в сборе.. Not Shown 15RP Models Only (CARBURETOR ASSY.. Not Shown 15RP Models Only)

   (последний код) CARB AY,15HP

Карбюратор в сборе.. Not Shown 15KC Models Only (CARBURETOR ASSY.. Not Shown 15KC Models Only)

Винт, Adjustment (SCREW, Adjustment)

   (последний код) SCREW

Пружина, Игольчатый клапан (SPRING, Needle valve)

Ролик (ROLLER)

Уплотнительное кольцо, Cam folнижний (O-RING, Cam follower)

   (последний код) O-RING

Рычаг (LEVER)

Шайба, Сливной винт. Also included in kit 436359 (WASHER, Screw plug. Also included in kit 436359)

Соединитель, Folнижний 10 Models Only 15RP Models Only (LINK, Follower. 10 Models Only 15RP Models Only)

Соединитель, Folнижний 15KC Models Only (LINK, Follower. 15KC Models Only)

Прокладка, Bowl. Also included in kit 436359 (GASKET, Bowl. Also included in kit 436359)

   (последний код) GASKET

ORIFICE, Intermediate № 16. 15KC Models Only (ORIFICE, Intermediate No. 16. 15KC Models Only)

Крышка, Карбюратор Корпус. 10 Models Only (COVER, Carburetor body. 10 Models Only)

Крышка, Карбюратор Корпус. 15RP Models Only 15KC Models Only (COVER, Carburetor body. 15RP Models Only 15KC Models Only)

   (последний код) COVER&INSERT AY

Прокладка крышки. Also included in kit 436359 (GASKET, Cover. Also included in kit 436359)

   (последний код) GASKET,CARB.

Прокладка крышки. Also included in kit 436359 (GASKET, Cover. Also included in kit 436359)

Винт, Поплавковая камера & Крышка (SCREW, Float chamber & cover)

Винт заглушки (SCREW, Plug)

Шайба, Idle passage. Also included in kit 436359 (WASHER, Idle passage. Also included in kit 436359)

Игольчатый клапан, Slow speed (NEEDLE VALVE, Slow speed)

Поплавковая камера (FLOAT CHAMBER)

Сливной винт, Idle passage. 10 Models Only 15RP Models Only (SCREW PLUG, Idle passage. 10 Models Only 15RP Models Only)

Шланг FITTING, Крышка. 15KC Models Only (HOSE FITTING, Cover. 15KC Models Only)

Ниппель, Primer (NIPPLE, Primer)

HINGE Стопор поплавка. Also included in kit 436359 (HINGE PIN, Float. Also included in kit 436359)

Клапан поплавка & Седло в сборе.. Also included in kit 436359 (FLOAT VALVE & SEAT ASSY.. Also included in kit 436359)

   (последний код) FLOAT-VALVE

Шайба. Also included in kit 436359 (WASHER. Also included in kit 436359)

Пружина Зажим. Also included in kit 436359 (SPRING CLIP. Also included in kit 436359)

   (последний код) CLIP

HIGH SPEED ORIFICE, № 37. 10 Models Only (HIGH SPEED ORIFICE, No. 37. 10 Models Only)

HIGH SPEED ORIFICE, № 48. 15RP Models Only (HIGH SPEED ORIFICE, No. 48. 15RP Models Only)

HIGH SPEED ORIFICE, № 62. 15KC Models Only (HIGH SPEED ORIFICE, No. 62. 15KC Models Only)

Поплавок в сборе.. Also included in kit 436359 (FLOAT ASSY.. Also included in kit 436359)

   (последний код) FLOAT&ARM AY

Винт. 10 Models Only 15RP Models Only (SCREW. 10 Models Only 15RP Models Only)

Зажим. 10 Models Only 15RP Models Only (CLIP. 10 Models Only 15RP Models Only)

   (последний код) CLIP

Штифт, Choke Рычаг. 10 Models Only 15RP Models Only (PIN, Choke lever. 10 Models Only 15RP Models Only)

   (последний код) PIN

Колпачок, Primer Ниппель. 10 Models Only 15RP Models Only (CAP, Primer nipple. 10 Models Only 15RP Models Only)

Колпачок, Рестриктор. 10 Models Only 15RP Models Only (CAP, Restrictor. 10 Models Only 15RP Models Only)

Колпачок, Рестриктор. 15KC Models Only (CAP, Restrictor. 15KC Models Only)

Заглушка, Expansion, nozzle well (PLUG, Expansion, nozzle well)

Пружина, Idle adjustment. 15KC Models Only (SPRING, Idle adjustment. 15KC Models Only)

   (последний код) SPRING

Винт, Idle adjustment. 15KC Models Only (SCREW, Idle adjustment. 15KC Models Only)

Шайба, Винт. 10 Models Only 15RP Models Only (WASHER, Screw. 10 Models Only 15RP Models Only)

   (последний код) WASHER

Прокладка. Also included in kit 436359 (GASKET. Also included in kit 436359)

Гайка, Карбюратор Креплениеing (NUT, Carburetor mounting)

   (последний код) NUT

AIR Глушитель. 10 Models Only 15RP Models Only (AIR SILENCER. 10 Models Only 15RP Models Only)

   (последний код) SILENCER,AIR

Воздушный винт Глушитель. 10 Models Only 15RP Models Only (SCREW, Air silencer. 10 Models Only 15RP Models Only)

Крепёжный хомут, Кабели to Глушитель (TIE STRAP, Cable to silencer)

   (последний код) TIE-STRAP

Сальник, Air Глушитель to carb.. 10 Models Only 15RP Models Only (SEAL, Air silencer to carb.. 10 Models Only 15RP Models Only)

Заглушка, Air Глушитель. 10 Models Only 15RP Models Only (PLUG, Air silencer. 10 Models Only 15RP Models Only)

Ремкомплект карбюратора. 10 Models Only 15RP Models Only (CARBURETOR REPAIR KIT. 10 Models Only 15RP Models Only)

   (последний код) KIT AY,CARB REPAIR

Ремкомплект карбюратора. 15KC Models Only (CARBURETOR REPAIR KIT. 15KC Models Only)
