Запчасть снята с производства - The Spare Part Is Laid Off (MODEL:90, <-3201-95D70) (The Spare Part Is Laid Off)

Запчасть снята с производства - The Spare Part Is Laid Off (MODEL:91~98) (The Spare Part Is Laid Off)

Запчасть снята с производства - The Spare Part Is Laid Off (MODEL:99, 00) (The Spare Part Is Laid Off)

Запчасть снята с производства - The Spare Part Is Laid Off (MODEL:91~98) (The Spare Part Is Laid Off)

Карбюратор в сборе, 2nd - Carburetor Assy, 2nd (Carburetor assy, 2nd # MODEL:99, 00 ) (Carburetor Assy, 2nd)

Запчасть снята с производства - The Spare Part Is Laid Off (MODEL:90) (The Spare Part Is Laid Off)

Карбюратор в сборе, 3rd - Carburetor Assy, 3rd (Carburetor assy, 3rd # MODEL:91~98 ) (Carburetor Assy, 3rd)

Карбюратор, 3rd - Carburetor, 3rd (MODEL:99) (Carburetor, 3rd)

   (актуальный код замены) Запчасть снята с производства - The Spare Part Is Laid Off

Карбюратор, 3rd - Carburetor, 3rd (Carburetor assy, 3rd ) (Carburetor, 3rd)

Карбюратор, 3rd - Carburetor, 3rd (Carburetor assy, 3rd # MODEL:00 ) (Carburetor, 3rd)

Контрольная форсунка (62.5) - Jet, Pilot (625) (Jet, pilot (62.5) # MODEL:91~98 ) (Jet, Pilot (62.5))

Контрольная форсунка (65) - Jet, Pilot (65) (Jet, pilot (65) # #1, MODEL:99, 00 ) (Jet, Pilot (65))

Контрольная форсунка (70) - Jet, Pilot (70) (Jet, pilot (70) # MODEL:89 ) (Jet, Pilot (70))

Контрольная форсунка (72.5) - Jet, Pilot (725) (MODEL:90 <-9492-72002 ) (Jet, Pilot (72.5))

Контрольная форсунка (75) - Jet, Pilot (75) (Pilot jet (75) # #3, MODEL:99, 00 ) (Jet, Pilot (75))

Запчасть снята с производства - The Spare Part Is Laid Off (#2, MODEL:99, 00) (The Spare Part Is Laid Off)

Главная форсунка - Nozzle, Main (Nozzle, main # <-3235-95D10 ) (Nozzle, Main)

Запчасть снята с производства - The Spare Part Is Laid Off (#1, MODEL:99, 00) (The Spare Part Is Laid Off)

Запчасть снята с производства - The Spare Part Is Laid Off (#2, MODEL:99, 00) (The Spare Part Is Laid Off)

Запчасть снята с производства - The Spare Part Is Laid Off (#3, MODEL:99, 00) (The Spare Part Is Laid Off)

Колпачок, Главная форсунка - Cap, Main Nozzle (Cap, Main Nozzle)

Поплавок - Float (<-3250-95D00 ) (Float)

Прокладка поплавковой камеры - Gasket, Float Cahmber (Gasket, float chamber ) (Gasket, Float Cahmber)

Стопор поплавка - Pin, Float (Pin, float ) (Pin, Float)

Регулятор - Adjuster (Adjuster)

Пружина, Дроссель Винт - Spring, Throttle Screw (Spring, throttle screw ) (Spring, Throttle Screw)

Главная форсунка (130) - Jet, Main (130) (Jet, main (#130) # #3, MODEL:99, 00 ) (Jet, Main (130))

Главная форсунка (145) - Jet, Main (145) (Jet, main (145) # MODEL:88~90 ) (Jet, Main (145))

Главная форсунка (102.5) - Jet, Main (1025) (Jet, main (#102.5) # #2, MODEL:99, 00 ) (Jet, Main (102.5))

Главная форсунка (105) - Jet, Main (105) (Jet, main (#105) # #1, MODEL:99, 00 ) (Jet, Main (105))

Главная форсунка (120) - Jet, Main (120) (MODEL:91~98 <-9491-24012 ) (Jet, Main (120))

Регулятор - Adjuster (MODEL:89 ) (Adjuster)

Винт контроля воздуха - Screw, Pilot Air (Screw, pilot ) (Screw, Pilot Air)

Пружина, Дроссель Винт - Spring, Throttle Screw (Spring, throttle screw ) (Spring, Throttle Screw)

Винт - Screw (Screw, vacuum sw valve ) (Screw)

Шайба с блокировкой - Washer, Lock (Washer, Lock)

   (актуальный код замены) Шайба с блокировкой - Washer, Lock

Шайба с блокировкой - Washer, Lock (Washer, Lock)

Датчик, Клапан дросселя - Sensor, Throttle Valve (Sensor assy, throttle valve # FOR 2ND CARB <-7810-95D04 ) (Sensor, Throttle Valve)

Винт - Screw (Screw)

Шайба с блокировкой - Washer, Lock (Washer, Lock)

   (актуальный код замены) Шайба с блокировкой - Washer, Lock

Шайба с блокировкой - Washer, Lock (Washer, Lock)

Тяга дросселя - Rod, Choke (Rod, Choke)

Запчасть снята с производства - The Spare Part Is Laid Off (751282~) (The Spare Part Is Laid Off)

Поплавок, Chamber - Float, Chamber (Froat chamber ) (Float, Chamber)

Игольчатый клапан, в сборе - Valve Assy, Needle (Valve assy, needle # MODEL:91~00 ) (Valve Assy, Needle)

Игольчатый клапан - Valve, Needle (MODEL:88~90 ) (Valve, Needle)

Винт - Screw (Screw)

Шайба, Choke Рычаг - Washer, Choke Lever (Washer ) (Washer, Choke Lever)

Пружина, Дроссель Винт - Spring, Throttle Screw (Spring, throttle screw ) (Spring, Throttle Screw)

Шайба - Washer (Ring, friction ) (Washer)

Стопор пружины - Spring Pin (Spring Pin)

Штифт - Pin (751282~ ) (Pin)

Прокладка - Gasket (Gasket # 751282~ ) (Gasket)

Воздушная форсунка (1.0) - Jet, Air (10) (Jet, pilot air (1.0) # #1, #3 MODEL:99, 00 ) (Jet, Air (1.0))

Контрольная форсунка Air, 1.4 - Jet, Pilot Air, 14 (#2 MODEL:99, 00 ) (Jet, Pilot Air, 1.4)

Главная форсунка (130) - Jet, Main (130) (Jet, main (#130) # OPT <-9491-26009 ) (Jet, Main (130))

Главная форсунка (140) - Jet, Main (140) (Jet, main (#140) # OPT <-9491-28017 ) (Jet, Main (140))

Главная форсунка (150) - Jet, Main (150) (Jet, main (#150) # OPT ) (Jet, Main (150))

Главная форсунка (115) - Jet, Main (115) (Jet, main (#115) # OPT ) (Jet, Main (115))

Главная форсунка (120) - Jet, Main (120) (OPT <-9491-24012 ) (Jet, Main (120))

Тяга управления дросселем - Rod, Throttle Control (Rod, throttle control ) (Rod, Throttle Control)

Рукоятка стартера - Knob, Starter (<-3631-93500 ) (Knob, Starter)

Втулка - Bush (<-9305-04005 ) (Bush)

   (актуальный код замены) Подушка, Muf Cov - Cushion, Muf Cov

Соединитель тройника - Joint, 3 Way (3 way ) (Joint, 3 Way)

Шланг (5x9x600) - Hose (5x9x600) (L:600->0/5.0X9.0X300 ) (Hose (5x9x600))

   (актуальный код замены) Шланг (5x9x600) - Hose (5x9x600)

Шланг (5x9x600) - Hose (5x9x600) (L:600->40/5.0X9.0X300 ) (Hose (5x9x600))

   (актуальный код замены) Шланг (5x9x600) - Hose (5x9x600)

Зажим - Clip (Clip)

Гайка - Nut (Nut)

Ремкомплект карбюратора - Repair Kit, Carburetor (Repair kit, carburetor # OPT, NOT SHOWN ) (Repair Kit, Carburetor)
